Experts in Nanometer Accuracy

20µm Linear Glass Scales

Key Features

  • Built to Order
  • Reduce manufacturing issues
    • Highest Quality and Extremely low defects
    • PSA Backing available
    • UV Curable coatings available
  • Maximize Performance of any Encoder
    • Improve Accuracy with Ultra Precision Sub-Micron Photolithography
    • Optimize Contrast Ratio with Coating process options
  • Glass, Stainless Steel, and PET materials

Compliance

Life Cycle:
Active
Certification 1
Certification 1
Overview

20µm soda-lime glass precision scales complement high resolution optical reflective read head encoder modules. Nanometer photolithography creates accurate and repeatable patterns.

Production scales match the encoder, physical, environmental, and performance requirements. Coatings are processed for specific wavelengths matched to requirements. For applications requiring best accuracies over long lengths or over temperature range, glass compositions with very low CTE are available.

Specifications

LG2 Series 20µm Linear Glass Scales

Filter, search, and sort inventory data below.

SKU Indexes Length Width Total Thickness PSA Tape Thickness
LG21R20-5-0.5CA 1 20mm 5mm 0.5mm No PSA Tape
LG21R20-5-0.55CAT1 1 20mm 5mm 0.55mm 0.05mm PSA Tape
LG21R23-6-0.55CA 1 23mm 6mm 0.55mm No PSA Tape
LG21R23-6-0.6CAT1 1 23mm 6mm 0.6mm 0.05mm PSA Tape
LG21R23-6-0.75CAT2 1 23mm 6mm 0.75mm 0.2mm PSA Tape
LG21R32-6-0.55CA 1 32mm 6mm 0.55mm No PSA Tape
LG21R32-6-0.6CAT1 1 32mm 6mm 0.6mm 0.05mm PSA Tape
LG20R37-3-0.7CA No Index 37mm 3mm 0.7mm No PSA Tape
LG20R37-3-0.75CAT1 No Index 37mm 3mm 0.75mm 0.05mm PSA Tape
LG21R37-3-0.7CA 1 37mm 3mm 0.7mm No PSA Tape
LG21R37-3-0.75CAT1 1 37mm 3mm 0.75mm 0.05mm PSA Tape
LG21R70-5-1.05CAT1 1 70mm 5mm 1.05mm 0.05mm PSA Tape
LG21R70-5-1.2CAT2 1 70mm 5mm 1.2mm 0.2mm PSA Tape
LG21R70-5-1CA 1 70mm 5mm 1mm No PSA Tape
LG23R110-5-1.05CAT1 Three Indexes 110mm 5mm 1.05mm 0.05mm PSA Tape
LG23R110-5-1CA Three Indexes 110mm 5mm 1mm No PSA Tape
No matches found for the applied filters.
Documents
Datasheets
pdf
VC America Electronics Scale Datasheet
VC America Electronics Scale Datasheet

LG2

20µ Linear Glass Scales
Availability:

In stock

SKU:
LG2
Scale Material:
Glass

Product Options:

As low as: $11.20
Available At

More Information

Product Name 20µm Linear Glass Scales
Life Cycle Active
Track Width (mm) 2.000000
Width (mm) 3.000000
Pitch (µm) 20
Thickness (mm) 0.700000
Compatible Encoder SMD-04B, SMD-01B
Scale Material Glass
Coating Reflective Pattern with Anti-Reflective coating
Index Count 0
Index Position(s) No Index
